Gemma-4 31B + vLLM on RTX 6000 PRO : 1.17k tokens/sec and still asking for more

Throughput, latency, and queue depth for Gemma-4 31B served on vLLM under progressive load, from 12 to 24 concurrency The numbers that matter: 1.17k tok/s peak, ~0.7s median TTFT, and tail latency as the one thing to watch.

Updated
•5 min read•View as Markdown
Gemma-4 31B + vLLM on RTX 6000 PRO : 1.17k tokens/sec and still asking for more
H
HexGrid.cloud
HexGrid.cloud is a private AI cloud for deploying models, renting dedicated GPUs, and running production AI workloads without managing infrastructure. Managed Inference: For managed inference, teams can choose a model, configure precision and context length, select the appropriate GPU, and launch a secure OpenAI-compatible HTTPS endpoint in minutes. HexGrid.cloud handles GPU compatibility, CUDA and PyTorch dependencies, inference-engine configuration, quantization, memory allocation, SSL, authentication, observability, and rate limiting. Compute Infrastructure: For teams that need full infrastructure control, HexGrid.cloud also provides dedicated GPU instances with SSH and root access. Developers can bring their own containers, frameworks, notebooks, training code, checkpoints, and CUDA workloads for model training, fine-tuning, batch processing, and custom compute. ComfyUI Deployments: HexGrid.cloud also provides private ComfyUI deployments for generative video and image workflows, with models, checkpoints, VAEs, text encoders, LoRAs, and runtime dependencies provisioned automatically. Teams can run models such as MiniMax, Wan, and LTX on dedicated GPUs while retaining control over custom nodes, workflows, weights, and generated outputs. Infrastructure is available across US, EU, and APAC regions with GPU options ranging from cost-efficient RTX instances to L40S, H100, H200, B200, and other high-memory accelerators. Workloads run on dedicated hardware with private data and model isolation. Instead of stitching together GPU providers, CUDA environments, model servers, storage, HTTPS gateways, certificates, authentication, monitoring, and scaling infrastructure, HexGrid.cloud provides a unified platform for going from GPU or model selection to a running AI workload in minutes.

Model Overview

Gemma-4-31B-it-FP8 is a 30.7B parameter dense Transformer built by Google DeepMind, designed for frontier-level reasoning, coding, multimodal understanding, and agentic workflows. It supports a 256K-token context window, accepts text, image, and video input, and features a hybrid attention mechanism interleaving local sliding-window and full global attention with Proportional RoPE for long-context performance. The model includes native function calling, toggleable thinking mode for step-by-step reasoning, and multilingual support across 140+ languages.

This FP8-block checkpoint was quantized by RedHatAI using LLM Compressor, compressing the weights and activations of linear operators within transformer blocks to the FP8 data type while keeping the vision tower, embedding, and output head layers in their original precision.

HF path: https://huggingface.co/RedHatAI/gemma-4-31B-it-FP8-block

Model Name Gemma/Gemma-4 31B it
HF Checkpoint RedHatAI/gemma-4-31B-it-FP8-block
Quantization FP-8
Max model length (context) 4096

Hardware

GPU Name RTX PRO 6000 Blackwell
No of GPUS 1
VRAM 96GB
CPU 24 vCPU   with  218 GB RAM

Serving Engine

Engine vLLM
Version 0.20
Configs 'max_model_len': 4096, 'gpu_memory_utilization': 0.9, 'enable_prefix_caching': True, 'language_model_only': True, 'max_num_batched_tokens': 4096, 'max_num_seqs': 21, 'enable_chunked_prefill': True
Endpoint /v1/chat/completions

Dataset / Workload

Name ShareGPT sample
Unique Prompts 128 prompts per concurrency level
Conversation Shape Multi-turn response per request
Languages Multilingual with en/zh/ru/th/ko/fr/pl/ja
Max output tokens 1024
Temperature per prompt 0.2
Streaming ON
Concurrency Levels 12, 16, 20, 24

Performance Charts

Request Concurrency Timings in Charts

Concurrency Level Time Range in Chart
12 17:19 - 17:23
16 17:24 - 17:27
20 17:27 - 17:30
24 17:30 - 17:33

Token Throughput

Time To First Token (TTFT)

Queue Time

E2E Latency

TPOT Latency

Verdict

Showing Avg and Max only.

Figures are aggregated across the whole sweep, so Avg ≈ behavior across concurrency 12→24 and Max ≈ behavior at the top end (~concurrency 24) — not broken out per level.

Category Metric Avg Max Unit What it tells you
Throughput Prompt 444 708 tok/s Prefill rate; scales well under load
Output 380 548 tok/s Generation rate; the user-facing number
Total 823 1,168 tok/s Combined; peaks ~42% above average
Load Active requests 13.7 21 reqs Requests being processed concurrently
Queued requests 0.41 3 reqs Near-empty queue → server keeping up
E2E latency p50 27.1 35 s Typical full-response time
p95 40.1 51.3 s Slow-tail full-response time
p99 41.9 58.3 s Worst-case full-response time
TTFT p50 0.73 3.65 s Median time to first token — snappy
p95 2.82 15.6 s Tail first-token wait
p99 3.65 19.1 s Worst-case first-token wait spikes hard

Summary:

  • Server stayed healthy and unsaturated across the whole sweep. The clearest evidence is the queue: it averaged 0.41 and peaked at only 3 requests while ~14–21 requests were actively processing. Requests were being worked on, not waiting — the scheduler had headroom even at concurrency 24.

  • Throughput scaled cleanly to a 1,168 tok/s total peak (548 tok/s output). The gap between avg and max is just the ramp from concurrency 12 up to 24, which is expected.

  • High E2E latency (p50 27s, p99 58s) is driven by long generations, not server inefficiency. At 380 output tok/s across 14 active requests (27 tok/s per request), responses are roughly 700+ output tokens each. Long outputs naturally mean long end-to-end times; the near-zero queue confirms it isn't a backlog problem.

  • The one genuine stress signal is tail TTFT. Median first-token is excellent (~0.73s), but p99 spikes to 19s at peak load — under heaviest concurrency, a small fraction of requests wait noticeably before streaming starts. This is the first thing that degrades as you push higher.

Result

The vLLM server and Gemma-4 model didn't break a sweat. Near-zero queueing and ~1.17k tok/s throughput at concurrency 24 mean there's room to climb — high E2E latency is just long generations, and the only metric flexing under load is tail TTFT (p99 ~19s).

Complete Walkthrough Video

https://youtu.be/88ZbdsJYDxk
